CARACTERÍSTICAS Y BENEFICIOS LA CONSTRUCCIÓN DE BOMBA MÁS DURADERA DISPONIBLE La meticulosa selección de materiales garantiza una fiabilidad a larga vida.
• Cilindros y Cabezas de hierro fundido 100%
• Cigüeñal duradero y resistente a la corrosión
• Reduce el estrés térmico para una mayor confiabilidad
• Cilindros y Cabeza de hierro fundido con aletas profundas para funcionamiento en frío
• La bomba de giro lento aumenta la vida útil de la bomba DISEÑO INDUSTRIAL El compresor de aire alternativo más robusto de su clase.
• Proporciona presiones más altas, mejor eficiencia y mayor vida útil
• Listo para manejar aplicaciones resistentes y de servicio pesado QUALITY COMPONENTS Para una mayor vida útil del producto y un rendimiento continuo.
• Los rodamientos de rodillos principales de grado industrial se ajustan con precisión para soportar todas las partes giratorias
• El sistema de válvulas de acero inoxidable de alto flujo y servicio pesado ofrece más cfm por caballo de fuerza
• El intercooler robusto aumenta la eficiencia del compresor
• El filtro/silenciador de entrada de metal es superior al de plástico • Protector de banda de acero estampado de alta resistencia
• Descargadores de cabezal con válvula de succión para el funcionamiento continuo de los compresores de aire
Posted on 12 December, 2017 at 13:30 |
Â
A pressure switch is a device that senses changes in fluid pressure and responds in a specified way. An actuated pressure switch makes or disrupts electrical contact in order to either trigger an alarm or switch something on or off. Switches are programmed to activate at certain pressure points, and may be designed to make contact either on pressure rise or on pressure fall.
http://hkaircompressors.blogspot.com
Pressure switches (also called a vacuum switch) consist of a switch mechanism that is connected to a bellow or diaphragm that reacts to system pressure. They are selected by operating range and differential. Operating range is the pressure limits in which the switch will work. Differential is the difference between the cut-in and cut-out pressures. Pressure switch settings, common to many air compressors, are set for a range of 40 to 250 PSI and an adjustable differential of 35 to 60 PSI. This means that the lowest pressure that the switch can be set to close at is 40 PSI, and the highest pressure it can be set to open at is 250 PSI. The differential that is actually available to use varies with the pressure range you’re actually working in.
